JFT STRING Wound Filters are designed and manufactured using the latest winding technology. The filter comprises a dense layer on the inner side and a coarse layer at the outer end. Due to this, it produces a superior depth filter with increased capacity, longer service life and high performance that reduce the effective cost.
STRING filters have high structural integrity with huge void volume, giving a lower pressure drop. It had much-improved dirt holding capacity and efficiency compared to conventional wound filters.
Applications
- Hydraulic Oils & Lube Oils
- Paints & resins
- Ink
- Lacquers & Varnishes
- Fuel Oils Crude Oils Grease
- Adhesives
Features & Benefits
- Continuous Filament ensures no media migration
- True grade density by new winding technology
- High dirt holding capacity
- High void to solid ratio for low pressure drop.
- High structural integrity
- Media/ core can be easily incinerated with no hazardous volatiles for environment friendly disposal.
Filter Specification
Media: Polypropylene, Cotton & glass fiber
Structure: Polypropylene/ SS 304 / SS 316
End Caps: Polypropylene (PP)
Efficiency of Filter:0.5, 1, 3, 5, 10, 25, 50, 100 micron
End Connection: SOE (Optional) or DOE (Standard)
O Rings / Gaskets (for SOE): Buna N, EPDM, Silicone, Viton
Dimensions
Nominal lengths: 9.75, 10, 20, 30, 40 inches
Diameter: ID/OD: 1.1” (28 mm) / 2.5” (63 mm)
End connections: DOE (standard) / SOE (optional)
Max operating temperature: 80 C 120 C – Cotton with SS core 400 C – Heat purified glass fiber with SS core
Recommended Change out differential pressure: 35 PSID
